Specification of gear shaper SE25FR Plus

※1 module is a value indicating the size of the gear, equal to the pitch circle diameter (mm) divided by the number of teeth.

※ The 2 series name FR is derived from "Fine Pitch for Robot, Reducer". With the expansion of the market for industrial and life support robots, the demand for high-precision small modulus gears inside precision reducers used in robot joints has increased, and the series has been developed to meet this demand.

※3 refers to a mechanical device that uses the motion difference between the ellipse and the right circle to decelerate and output the power speed.

※4 Direct drive motor refers to the motor that transfers power directly to the drive object without the help of indirect mechanism such as gear box, which can inhibit the drive loss such as friction and parts loss.
